SMP5 power supply/charger converts a low voltage AC input into a 6VDC, 12VDC or 24VDC output. This unit has a wide range of applications for access control, security and CCTV system accessories that require additional power.

Input:

6VDC applications use TP1640.
12VDC applications use T2428100.
24VDC applications use T2428175.

Output:

6VDC, 12VDC or 24VDC selectable output.
4 amp supply current.
Filtered and electronically regulated outputs.
Short circuit and thermal overload protection.

Battery Backup:

Built-in charger for sealed lead acid or gel type batteries.
Maximum charge current 0.3 amp.
Zero voltage drop when switching over to battery backup.

Visual Indicators:

AC input and DC output LED indicators.

Electrical:

Operating temperature: 0° C to 49° C ambient.
BTU/Hr.:
– 6VDC: 12.28 BTU/Hr.
– 12VDC: 24.57 BTU/Hr.
– 24VDC: 49.13 BTU/Hr.
System AC input VA requirement:
– 6VDC: 55.2VA.
– 12VDC/24VDC: 115VA.

Features:

Extremely compact design.
Includes battery leads.
Snap Trac compatible (order Altronix model number ST3).
